90° Curve Belt Conveyor

Advantages:

  • PVC/PVK belt is oil-resistant, corrosion-resistant, and anti-static.
  • Stable and smooth conveying.
  • No relative movement between the material and the conveyor belt.
  • Low energy consumption and low vibration.
  • Conveyor with simple structure, easy for maintenance.
  • Narrow transition gap, and no stuck for conveying products.
Conveyor FormTurning Belt ConveyorKnife-edge Turning Belt Conveyor
Belt DataBelt MaterialPVC, PU
Belt Width(mm)250mm ≤ W ≤ 1000mm1000mm ≤ W ≤ 1600mm
Conveyor DataFrame MaterialCarbon Steel Coated/Stainless Steel 304,316L/Aluminium
Conveyor Width(mm)200 ~ 1700 ( Others to be Customized)
Conveyor Height(mm)700 ( Others to be Customized)
Turning Radius R(mm)250/400/600/900400/600/900/1200
Turning Degree45°/90°/180°/Customized
Speed(m/min)≤ 45

90° Curve Belt Conveyor is made of a flat PVC/PU/PVK belt, it plays an important role in turning part of the whole conveying line, as a transition part. The turning degrees could be 45°,90°,180°, or other customized ones.
